Cocktail Audio
Cocktail Audio X35 without hard drive (black / all-in-one HD music server with amplifier/CD ripper/DAC/DAB+/FM/DSD/PCM/FLAC/MM phono input/TIDAL/Qobuz/Highres Audio)
Article number: 11007463
1,699.00 €
3% discount: 1,648.03 €
For payment by cash in advance (bank transfer) or pickup on the spot
Sold out
Highlights
 |
All-in-One HD database-supported music server / network streamer / CD storage (ripper) / amplifier in black | |
|
digitize your old records and audio cassettes with up to 192kHz / 24-bit sampling rate | |
|
very good value for money | |
|
beautiful design and excellent workmanship | |
|
optimum performances - strong power handling | |
|
equipped with a Dual Core Cortex A9 Arm-Prozessor with 2×1 GHz | |
|
ESS ES9018K2M Sabre reference DAC (digital-to-analogue converter) | |
|
isolated power source circuit design for digital and analogue parts | |
|
combined with two separate high-performance Class D Amplifiers for left and right with total 200 watts | |
|
toroidal transformer to minimize idle noise | |
|
high speed optical disk drive for quick ripping | |
|
7 inch TFT LCD(1024 x 600 pixels) screen for intuitive GUI | |
|
HDMI Out connector for using an external screen like TV as its GUI screen | |
|
DAB+/FM Tuner built-in | |
|
Giga Fast Ethernet(10/100/1000Mbps) built-in | |
|
phono input (Moving Magnet) for turntables. Play LP directly and record it | |
|
supports up to 8TB (Tera Bytes) storage like 3.5"/2.5" hard disk or SSD - no hard drive supplied! | |
|
supports various file formats like DSD(64/128/256), DXD(24Bit/352.8Khz), PCM signal up to 32Bit/384Khz - including 24Bit/192Khz WAV/FLAC and full range hi-res audio file formats | |
|
recording function with hi-res sampling rate 192Khz/24-bit | |
|
high connectivity | |
|
versatile network functions | |
|
Major Music Streaming Services (TIDAL, Deezer, Qobuz) and Internet Radio available | |
|
rugged chassis contruction with 13mm thickness aluminum front and knobs with CNC cutting | |
|
provides customized WebInterface (WebUI) for remote control and MusicDB management by PC | |
|
customized Remote Control App, NOVATRON MusicX for iOS and Android | |
|
and much more… | |
|
power supply = AC 220V - 240V, 50/60Hz (for Europe) | |
|
we are specialized dealer for Cocktail Audio products - your authorized dealer in Leipzig |
Product Description
The CocktailAudio X35 is the consequent upgrade of the successful X30. The X35 is a highly innovative all-in-one hi-fi system with CD ripping, music server, network streamer, and music recording function. With a 200 watt amplifier it is the ideal device for instant music enjoyment.
Connect your record player directly to the X35 for playback or recording. Thus, you can easily digitize your vinyl or recordings.
Discover your own personal sound experience
In our living room studio "Klangvilla" in Leipzig we feature more Cocktail Audio products which are at all times ready for presentation. You will have the option to be explained and demonstrated also other high-quality high-end devices by our sales manager who will be available for you. We can also recommend the appropriate wiring and other high quality Hi-Fi accessories. Please just simply arrange a date for demonstration or consulting service with our home Hi-Fi sales manager by e-mail or by telephone.
Technical Data
| Specifications - Cocktail Audio - X35 | ||
| Prozessor / | Processor: | Dual Core ARM Cortex A9 2 x 1.0 GHz |
| Arbeitsspeicher / | RAM: | DDR-1066 1GByte |
| Firmwarespeicher / | Firmware memory: | 8 GByte |
| Typ CD-Player / | Type CD player: | Fronteinschub / front insertion |
| unterstützte Datenträger / | Supported media: | CD, CD-DA, CD-R, CD-RW, DVD-R/RW |
| Display / | Display: | 7 Zoll (17,8 cm) TFT-LCD Bildschirm (1024 x 600 Pixel), HDMI für externen Monitor/TV / 7 inch (17.8 cm) TFT LCD screen (1024 x 600 Pixel), HDMI for external monitor / TV |
| Bedienung / | Appliance: | Fernbedienung, PC, iOS & Android-Geräte mit benutzerdefinierter Weboberfläche oder kostenlosen UPnP Tablet- & Smartphone-Apps / Remote control, PC, iOS & Android devices with user-defined web interface or free UPnP tablet & smartphone apps |
| Audioformate / | Audio formats: | DSD (DSD 64, DSD 128, DSD 256, DXD (24 Bit/352,8 KHz), HD WAV (24Bit/192KHz), HD FLAC (24Bit/192KHz), APF/CUE, WAV, FLAC, ALAC, AIFF, AIF, AAC, M4A, MP3, WMA, Ogg Vorbis, PCM, M3U, PLS, etc. - keine kopiergeschützten Formate / no copy-protected formats |
| Verstärker (Lautsprecherausgang) / | Amplifier (loudspeaker out): | RMS Leistung / Rated output: 100W + 100W @ 1Khz, 8Ohm, 0,1% THD (Gesamt/total 200 Watt) |
| DAC Chip / | DAC chip: | Sabre32 ES9018K2M |
| Kopfhörer-Ausgang / | Headphone output: | 6,35 mm Anschluss / connection, 100mW+100mW@1Khz, 600 Ohm, 0.1% THD |
| Digitalausgänge / | Digital output: | 1x Koaxial: S/PDIF 75 Ohm Cinch/RCA, Unterstützte Abtastrate/supported sampling: bis zu/up to 24bit/192Khz
1x Toslink: S/PDIF, Unterstützte Abtastrate/supported sampling: bis zu/up to 24bit/192Khz 1x AES/EBU XLR: 110 Ohm; Abtastrate/supported sampling: Bis zu/up to 192Khz, 24 Bit 1x USB Audio: USB Audio Class 2.0 1x HDMI Out: HDMI Audio Out |
| Analogeingänge / | Analogue input: | 1x Line In: Cinch/RCA, L & R hinten/rear, 2V rms
1x Aux In: 3.5mm Klinkenstecker/jack, Gerätefront/front, Standard 1Vrms 1x Phono In: MM Input, Standard/default 7.5mVrms |
| Digitaleingang / | Digital input: | 1x Koaxial: Sample Rate: up to 24bit/192Khz
1x Toslink: Sample Rate: up to 24bit/192Khz 1x AES/EBU XLR: Sample Rate: up to 24bit/192Khz |
| Unterstützte Festplatten/ | Supported storage: | HDD 2.5" SATA bis zu/up to 2 TB
HDD 3.5" SATA bis zu/up to 8 TB SSD 2.5" SATA bis zu/up to 2 TB größere Datenspeicher werden per Firmwareupdate ermöglicht / bigger capacity of storage will be supported by firmware update |
| Verbindungen / | Connectivity: | 3x USB 3.0 (5V/1A) Geräterückseite/rear (1x für/for USB Audioausgang/Audio out)
1x USB 2.0 (5V/1A) Gerätefront, front Kabel/cable: Giga Fast Ethernet (10/100/1000Mbps) RJ-45 Ethernet 802.11 b/g/n WiFi USB Dongle |
| Internetdienste / | Internet services: | Internet Radio: Airable (Powerd by TuneIn)
Streaming Dienste / Online Music Services: TIDAL, Deezer, Qobuz, Spotify Connect |
| Netzwerkprotokolle / | Network protocols: | UPnP(DLNA) Server/Client/Media Renderer, Samba Server/Client, FTP Server, Web Server, etc |
| Unterstützte Sprachen / | Supported languages: | Englisch, Deutsch, Französisch, Spanisch, Italienisch, Polnisch, Niederländisch, Chinesisch, Russisch, Koreanisch, etc (weitere Sprachen auf Anfrage möglich) / English, German, French, Spanish, Italian, Polish, Dutch, Chinese, Russian, Korean, etc (other languages on request) |
| Stromversorgung / | Power supply: | Ringkerntransformator (analoges Audiosignal) / Toroidal Transformer (analogue audio signal)
500 W internes Schaltnetzteil (digitale Signale) / 500W internal SMPS (digital CPU management) 230V Bereich/area: AC 220V - 240V, 50/60Hz (für Europa / for Europe) |
Gehäusedaten / | Chassis data | Front: 13 mm dickes, CNC gefrästes massives Aluminium /13 mm thick, aluminum by CNC cutting
Drehregler: CNC gefrästes massives Aluminium /Rotary control: aluminum by CNC cutting Gehäuse: Metall / Housing: metal |
| Maße (BxHxT) / | Dimensions (WxHxD): | 441mm x 101mm x 330mm (ohne Standfüße / without feet)
441mm x 111mm x 330mm (mit Standfüßen / with feet) |
Scope of Delivery
- 1 x Cocktail Audio - X35 without hard drive in black
- 1 x remote control
- 1 x power cord
- 1 x user manual
